五軸加工中心NBFG-1220系列產品特點：

1.整機采用全護罩式防護，保護加工周圍不境清潔及人身安全。

2.X軸雙驅動及雙排加寬型直線導軌，使機架運行更快速、穩定。

3.全絲桿驅動方式，更具加工剛性。

4.采用高剛性龍門橋式結構，龍門電氣雙驅、高動態特性，模塊化設計、高轉速高效率，同時還具有很好的動靜剛性和穩定性，適合幾乎所有的輕合金、有色金屬和所有非金屬材料的三維輪廓型面的高速五軸加工。

產品適合模具、有色軟金屬、復合材料等復雜曲面加工。

主要參數:

諾伯特NF5系列加工中心詳情介紹

一、整體介紹 Overall introduction

諾伯特是國內先進的五軸加工中心設備專業生產商之一，前身為深圳鑫寶創機械制造有限公司，一直專注于非金屬CNC加工中心的研發及生產，具有豐富的數控機床生產經驗。其生產的NF-5系列五軸加工中心采用全鋼龍門架結構以及橫梁，臺面移動以及機器的行程范圍均可根據客戶的需要來定制,采用目前非金屬加工行業內非常成熟的臺灣新代系統進行控制，使機器的安全性及工作效率的發揮達到極致,生產效率得到極大提高.

Nobot is one of the most advanced professional manufacturers of five axis machining center equipment in China. Formerly known as Shenzhen xinbaochuang Machinery Manufacturing Co., Ltd., Norbert has been focusing on the R & D and production of non-metallic CNC machining center, and has rich experience in CNC machine tool production. Its five axis machining center adopts all steel gantry structure and crossbeam, table movement and machine travel range can be customized according to the needs of customers. At present, it adopts the very mature Taiwan new generation system in the non-metal processing industry to control, so that the safety and working efficiency of the machine can be maximized, and the production efficiency can be greatly improved.

該系列產品采用先進的龍門式雙工作臺移動結構，具有完美的高速銑床的銑削技術特性，移動式工作臺，確保機床具有最佳的動態運動特性和最佳的驅動剛性；工作臺平穩軸向移動，在加工時，五個軸向驅動刀具運動，圍繞工件進行加工，實現五軸五聯動立體運行，可實現單一工作臺加工，另一工作臺上料的不間斷式生產加工。產品廣泛應用于木工家具、裝飾、游艇、汽車整車模型、汽車覆蓋模型、模具制造、化工板材、航天電子、變電器、三維立體加工等非金屬加工領域。

This series of products adopt the advanced gantry type double worktable moving structure, which has the perfect milling technical characteristics of high-speed milling machine. The mobile worktable ensures that the machine tool has the best dynamic motion characteristics and the best driving rigidity. The worktable moves stably and axially. During the processing, the five axes drive the cutter movement, and process around the workpiece, so as to realize the five axes and five linkage three-dimensional operation The utility model can realize the continuous production and processing of the single working table and the material on the other working table. The products are widely used in woodworking furniture, decoration, yacht, automobile model, automobile cover model, mold manufacturing, chemical plate, aerospace electronics, transformer, three-dimensional processing and other non-metal processing fields.

二、結構介紹 Structure introduction

X軸：橫梁滑板（刀具）的水平移動

X axis: horizontal movement of cross beam slide plate (tool)

Y軸：臺板支架的前后移動

Y-axis: front and back movement of platen support

Z軸：橫梁滑板（刀具）的升降移動

Z axis: lifting movement of cross beam slide plate (tool)

C軸：刀具沿Z軸旋轉移動

C axis: the tool rotates and moves along the Z axis

A軸：刀具與Z軸的相對角度移動，完成傾斜面加工。

A axis: the relative angle of the tool and axis Z moves to finish the inclined surface processing.

三、工藝介紹 Process introduction

激光跟蹤測量 Laser tracking measurement

1、采用激光跟蹤儀測量大型零部件整體尺寸,確保裝配零件的精度。

The laser tracker is used to measure the overall size of large parts to ensure the accuracy of assembly parts.

2、采用激光跟蹤儀測試非金屬加工中心安裝整體精度,可對裝配運動程序進行系統補償,實現機床的高精度運動定位。

The laser tracker is used to test the overall installation accuracy of the non-metal machining center, which can compensate the assembly movement program systematically and realize the high-precision movement positioning of the machine tool.

關鍵部位精密裝配 Precision assembly of key parts

1、采用百分表邊測量邊裝配設備。

Use dial indicator to measure and assemble equipment.

2、裝配位置包括齒輪條、絲杠導軌/電機減速機/主軸等關鍵零部件的裝配。

The assembly position includes the assembly of key parts such as gear bar, lead screw guide rail / motor reducer / main shaft.

3、關鍵零部件裝配螺絲全部涂抹螺紋緊固膠,并配雙面防滑墊片。

All the assembly screws of key parts shall be coated with thread fastening adhesive and equipped with double-sided anti-skid gasket.

模具定制服務Mold customization service

1、氣動真空吸附。

Pneumatic vacuum adsorption.

2、強磁吸附定位。

Strong magnetic adsorption location.

3、機械夾持定位。

Mechanical clamping and positioning.

四、性能優勢 Performance advantages

1.操作簡單：通過在行業內摸索，機器編程在現有成熟軟件的基礎上開發出了專門針對不同產品加工的后處軟件HIPMIL，只需要把工件完整圖紙導入到后處理軟件加工即可

Simple operation: through exploring in the industry, machine programming develops the postprocessing software hipmil based on the existing mature software for different products processing, which only needs to import the complete drawings of the workpiece into the postprocessing software for processing

2.對操作員工的要求素質大大降低，無需招聘專業的操作人員；

The required quality of operators is greatly reduced, and there is no need to recruit professional operators;

3.最早進入汽車內飾行業進行推廣在汽車內飾行業的吸塑工件加工，成熟的加工方式有兩種模式：六軸機器人配主軸以及水刀切割兩種方式；

The first to enter the automotive interior industry to promote the processing of plastic parts in the automotive interior industry. There are two mature processing modes: Six Axis Robot with spindle and water cutter cutting;

六軸機器人加主軸切割主要有以下問題：

機器成本高：標準的機器人本體主要用國外進口的，工件比較大需要選擇臂展長負載重的機器人，增加了用戶的成本；

用工成本高：機器人操作以及編程需要高技術人才，增加了企業用工成本；

工作速度慢:六軸機器人在工作中很多工件需要6軸聯動，降低了切割工件的速度；

The main problems of six axis robot with spindle cutting are as follows:

High machine cost: the standard robot body is mainly imported from abroad, and the robot with long arm and heavy load needs to be selected when the workpiece is relatively large, which increases the user's cost;

High labor cost: robot operation and programming need high-tech talents, which increases the labor cost of enterprises;

Slow working speed: many workpieces of six axis robot need six axis linkage, which reduces the speed of cutting workpieces;

水刀切割主要有以下幾個問題：

設備成本高；

工作過程中耗電大，能耗高；

危險性大，在工作中容易發生工傷事故；

結合以上兩種加工方式存在的問題，非金屬加工五軸機正好整合了二者的優勢，迅速打開了汽車內飾加工行業的市場；

There are several main problems in water jet cutting:High cost of equipment;High power consumption and high energy consumption in working process;

It is dangerous and easy to have industrial accidents at work;

Combined with the problems of the above two processing methods, the non-metal processing five axis machine just integrates the advantages of the two, and quickly opens the market of the automobile interior processing industry;

4.完善的售后服務

為了快速響應售后服務，我公司在天津、濟南、青島、蘇州、上海以及深圳等地設有分公司，縮短了售后服務響應時間。

Perfect after-sales service：In order to quickly respond to after-sales service, our company has branches in Tianjin, Jinan, Qingdao, Suzhou, Shanghai, Shenzhen and other places, reducing the response time of after-sales service.

五、 主要應用行業

人造石及亞克力衛浴產品加工及其木模造型, 曲木浴室家具修邊，玻璃鋼模具及修邊、厚片吸塑產品修邊，吸塑模具造型及塑料修邊、鑄造木模、代木模具、保麗龍、泡沫型、石蠟模具、石膏模具、油泥模型、汽車主模型、乘用車以及客車內飾件加工、拉桿箱行業修邊沖孔、汽車輪胎模具等.

Artificial stone and acrylic sanitary products processing and wood mold modeling, Curved wood bathroom furniture trimming, FRP mold and trimming, thick plastic suction products trimming, plastic mold molding and plastic trimming, casting wood mold, wood mold, dragon, foam, paraffin mold, plaster mold, oil sludge model, car master model, passenger car and bus interior trim processing, pull rod box industry trimming and punching, automobile tire mold and so on.

六、供應產品類型

汽車內飾五軸加工中心，飛機內飾五軸加工，塑料修邊五軸加工中心，塑料五軸加工中心，鋁模五軸加工中心，，泡沫五軸加工中心，消失模五軸加工中心，保麗龍五軸加工中心，石膏模具五軸加工中心，石蠟模具五軸加工中心，衛浴模具五軸加工中心，木模五軸加工中心，人造石五軸加工中心，亞克力五軸加工中心，家具五軸加工中心，玻璃鋼模具五軸加工中心，吸塑產品修邊五軸加工中心等；

Automotive interior five axis machining center, aircraft trim five axis machining, plastic trimming five axis machining center, plastic five axis machining center, aluminum mold five axis machining center, foam five axis machining center, lost foam five axis machining center, pliolon five axis machining center, gypsum mold five axis machining center, wax mold five axis machining center, bathroom mold five axis machining center, wooden mold five axis Processing center, artificial stone five axis processing center, acrylic five axis processing center, furniture five axis processing center, FRP mold five axis processing center, blister product trimming five axis processing center, etc;
